Herkunftsort: | Guangdong, China |
Markenname: | KAILITE |
Modellnummer: | P6 |
Min Bestellmenge: | 2 |
---|
Pixel -Tonhöhe: | 6 mm | Modulgröße: | 192*192mm |
---|---|---|---|
Körperliche Dichte: | 27777dots/sqm | Pixelkonfiguration: | 1R1G1B |
LED -Chip: | SMD3535 | Modulauflösung: | 32*32 |
Modulenergie: | 35W | Blickwinkel: | H: 120 °; V: 120 ° |
Optimale Entfernung: | 6-70 m | Maximale Leistung: | 900W |
Kabinettsgröße: | W: 960 mm*H: 960 mm | Kabinettsauflösung: | 96*96 |
Fahrmethode: | Konstantstrom 1/4 Scan | Rahmenfrequenz: | ≥ 60 Hz |
Frequenz aktualisieren: | ≥ 1200 Hz | ||
Hervorheben: | P6 outdoor LED display screen,SMD 3535 LED display,6500cd/sqm outdoor LED screen |
Attribute | Value |
---|---|
Use | Outdoor |
Tube Chip Color | FULL COLOR |
Display Function | Video |
Pixels | 6mm |
Screen Dimension | Customized Size |
Product Name | Factory direct led tv full color smd screen sign outdoor p6 |
Brightness | 6500cd/sqm |
Application | Outdoor |
LED Chip | SMD 3535 |
Module Size | 192*192mm |
Certificate | CE RoHS FCC Certifications |
Viewing Angle | H120° V120° |
Life Span | 100000 hours |
Warranty | 2 years |
Driving Method | 1/8 Scan Constant Current |
LED technology has revolutionized visual displays worldwide. As a premier application of this technology, our LED screens deliver exceptional visual and auditory experiences, transforming events into vibrant spectacles.
SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD specializes in manufacturing high-quality LED displays. We provide complete, customized LED screen solutions at competitive prices with guaranteed quality.
Item | P6 |
---|---|
Pixel Pitch | 6mm |
Module Size | 192*192mm |
Physical Density | 27777dots/sqm |
Pixel Configuration | 1R1G1B |
LED Chip | SMD3535 |
Module Resolution | 32*32 |
Module Power | 35w |
Viewing Angle | H:120°;V:120° |
Optimal Viewing Distance | 6-70m |
Maximum Power | 900w |
Cabinet Size | W:960mm*H:960mm |
Cabinet Resolution | 96*96 |
Driving Method | Constant current 1/4 scan |
Frame Frequency | ≥60Hz |
Refresh Frequency | ≥1200Hz |
Brightness | ≥6500cd |
Operation Temperature/Humidity | -30℃~+45℃ 10%~95% |
Input Voltage | 220V±10%/110V±10% |
Ingress Protection | Front IP:67:Back IP:65 |
Gray Scale/Color | ≥16.7M color |
Brightness Control | Manual/Automatic |
Input Signal | RF/S-Video/RFB/etc. |
Control System | PCTV+DVI video card control card fiber |
MTBF | >5,000hrs |
Life Time | >100,000 hours |
Lamp Failure Frequency | <0.0001 |
Yes, we offer indoor LED screens in P2.5, P3, P3.91, P4, P4.81, P5, P6, P7.62, P10 and outdoor LED screens in P5, P6, P8, P10.
Yes, we're a 10-year factory offering 2-year warranty with lifetime maintenance.
Our screens support videos, flash animations, WAV/MIDI audio, PowerPoint presentations, images and more.
Delivery typically takes 15-25 days after receiving deposit.
We pack goods in wooden or flight cases, shipping by air or sea.
We are confident our service and quality will satisfy you!
Trust us! We won't let you down
Send your inquiry details below and click "Send" now!
